YJFJ-20 Pipe Cutting Machine Flying Sawing Machine for Steel Pipe in Welding Pipe Production Line

Brand Name : YJ

Model Number : YJFJ-20

Certification : ISO9001 CE

Place of Origin : Jiangsu,China

MOQ : 1 set

Price : $6000-$20,000.00 sets

Supply Ability : 200 Sets per Year

Delivery Time : 60 days

Packaging Details : Seaworthy packing

material : Carbon Steel,hot or cold roll steel, galvanized steel

pipe thickness : 0.4-2.0mm

pipe diameter : 10-25.4mm

speed : 0-100m/min

Contact Now

Flying saw machine is an important equipment in the welded pipe production line.It automatically and accurately cuts various shapes of pipes at high speed to achieve the steel pipes of our required length.The Fixed length synchronization performance is good, and the mechanical transmission is reliable, so this machine has the characteristics of fast performance and high precision.

YJFJ-20 Pipe Cutting Machine Flying Sawing Machine for Steel Pipe in Welding Pipe Production Line

常规标准型号 Regular standard model	建议切割管径(mm) Recommended Cut diameter	适用厚度(mm) Applicable Thickness	生产速度 (米/分钟) Production Speed(M/Min)
YJFJ-20	Φ10-Φ25.4	0.4-1.5	0-100
	8x8-20x20	0.4-1.0
	10x6-25x15	0.4-1.0
YJFJ-32	Φ12.7-Φ38.1	0.4-2.0	0-120
	10x10-30x30	0.4-1.5
	12x8-40x20	0.4-1.5
YJFJ-50	Φ19.1-Φ63.5	0.6-3.0	0-100
	15x15-50x50	0.6-2.5
	20x10-60x40	0.6-2.5
YJFJ-76	Φ38.1-Φ89	0.8-3.5	0-80
	30x30-70x70	0.8-3.0
	40x20-80x60	0.8-3.0
YJFJ-89	Φ50-Φ102	1.0-4.0	0-70
	40x40-80x80	1.0-3.5
	50x30-90x70	1.0-3.5
YJFJ-102	Φ50-Φ114	1.2-4.5	0-70
	40x40-90x90	1.2-4.0
	50x30-100x80	1.2-4.0
YJFJ-114	Φ63.5-Φ127	1.5-5.0	0-60
	50x50-100x100	1.5-4.2
	60x40-120x80	1.5-4.2
YJFJ-127	Φ63.5-Φ140	1.5-5.0	0-60
	50x50-110x110	1.5-4.5
	60x40-130x90	1.5-4.5
YJFJ-165	Φ76-Φ165	1.5-6.0	0-50
	60x60-130x130	1.5-5.0
	70x50-150x110	1.5-5.0
YJFJ-219	Φ89-Φ219	2.0-8.0	0-50
	70x70-170x170	2.0-7.0
	80x60-190x150	2.0-7.0
YJFJ-254	Φ114-Φ254	3.0-9.0	0-40
	90x90-200x200	3.0-7.5
	100x80-250x150	3.0-7.5
YJFJ-273	Φ140-Φ273	4.0-10.0	0-30
	110x110-215x215	4.0-8.5
	130x90-250x180	4.0-8.5
